Elitech range of auto cycle 2 Axis servo made NC Cylindrical Grinding Machines are well accepted by industrial establishments worldwide as excellent performing for various OD and ID grinding applications. EMTU+ series is easy operating control station well designed various grinding cycle, features and good option against CNC automation. It is hassle free setting of auto cycle and not require skilled programmer like CNC. Elitech feels glad to say that clients appreciate worldwide as high performing auto cycle grinding machine at low prices. EMTU+ series is escalated version of EMTU series with extra features of automation.
Download Product Broucherideally for small and medium variety components for tool room grinding application as well as batch production and mass production.
| Specifications | unit | EMTU 450+ / 600+ / 800+ | EMTU 1000+ / 1250+ / 1500+ |
|---|---|---|---|
| Center Height | MM | 150 (200) | 150 (200) |
| Admit Between Centers | MM | 450 / 600 / 800 | 1000 / 1250 / 1500 |
| Max. Work Table Stroke | MM | 600 / 750 / 950 | 1150 / 1400 / 1650 |
| Max. Component Weight (ABC) | KG | 60 | 90 |
| Grinding Wheel Size (O.D. × width) | MM | 350 × 40 (400 × 40) | 400 × 40 (500 × 40/50) |
| Grinding Wheel Power | KW | 2.2 (3.7) | 3.7 (5.5) |
| Control System | - | NC | NC |
