CNC Cylindrical Grinding Machine (Straight)

CNC Cylindrical Grinding Machine (Straight)

Series:

Elitech economic series of CNC Cylindrical Grinding Machine with straight wheel head travelling has expressly designed to simple grinding with mass production in low price in its class. This CNC grinding machine can work on variety of plunge as well as reciprocating grinding applications to satisfy all users need for a wide range of applications in production environments. We hold special expertise in manufacturing CNC grinding machine and we offer our products with technical support for easy operation to verity of components. For years, we have worked with our clients and technology partners closely to develop state-of-the-art CNC cylindrical grinding machines that push the limits of engineering performances.

Download Product Broucher

Ideal for

ideally suited for high precision cylindrical grinding applications for mass production of fuel injection parts, transmission gears, motor shafts, cam shafts of engine, various auto components etc.

Specification

SpecificationsunitsECG 450 / 600 / 800ECG 1000 / 1250 / 1500
Center HeightMM150 (200)150 (200)
Admit Between CentersMM450 / 600 / 8001000 / 1250 / 1500
Max. Work Table StrokeMM600 / 750 / 9501150 / 1400 / 1650
Max. Component Weight (ABC)KG6090
Grinding Wheel Size (O.D. × width)MM350 × 40 (400 × 40)400 × 40 (500 × 40/50)
Grinding Wheel PowerKW2.2 (3.7)3.7 (5.5)
CNC Controller-Siemens / FanucSiemens / Fanuc

Features

  • Tercite-B coated guide ways for all movable slides
  • Graded casting as per IS:210
  • Cartridge type grinding wheel spindle
  • Partial enclosed machine guarding
  • Auto grinding as well as auto dressing cycle for various grinding applications

Optional

  • Internal Grinding Attachment
  • Touch probe censor
  • In-process gauging system
  • Linear glass scale
